AGM Batteries AGM Battery High Performance(DMH) Series
AGM Batteries AGM Battery High Performance(DMH) Series
Product name：AGM Batteries AGM Battery High Performance(DMH) Series
Item：33
Details：
AGM Battery High Performance(DMH) Series
Features&Benefits
Computer optimized grid and plate design for high power output;
Battery case material is available in both HBO or flame retardant V0 (UL94);
High quality lead-tin-calcium alloy grids;
Usable in any orientation;
Applications
Office Machines and Computers, TelecommDMications; UPS Equipment; Electrical facilities; Vending machine
Battery Type Nominal Veltage (V)  Capacity Ah Watts/cell  Dimension(±1mm) Weight(±5%)  Terminel Type PDF
10hr rate to 1.8V/cell 15min rate to 1.67V/cell Length Width Height Total Height (approx) kg (approx) poDMd
mm in mm in mm in mm in
DMH12-24W 12 6 24 151 5.94 50 1.97 94 3.7 100 3.94 1.75 3.86 F2
DMH12-26.5W 12 6.5 26.5 151 5.94 52 2.05 93 3.66 99 3.9 2 4.41 F2
DMH12-33W 12 7.7 33 151 5.94 65 2.56 94 3.7 100 3.94 2.45 5.4 F2
DMH12-35W 12 8.2 35 151 5.94 65 2.56 93 3.66 99 3.9 2.45 5.4 F1
DMH12-37W 12 9 37 151 5.94 65 2.56 93 3.66 99 3.9 2.6 5.73 F1
DMH12-55W 12 14 55 151 5.94 98 3.86 95 3.74 101 3.98 3.9 8.6 F2
DMH12-77W 12 17 77 181 7.13 77 3.03 167 6.57 167 6.57 5.6 12.3 F13
DMH12-92W 12 40.5 92 181 7.13 77 3.03 167 6.57 167 6.57 6.3 13.89 F13
DMH12-100W 12 26 100 166 6.54 175 6.89 125 4.92 125 4.92 8.6 18.95 F13
DMH12-120W 12 27 120 165 6.5 125 4.92 175 6.89 175 6.89 8.8 19.4 F13
DMH12-150W 12 32 150 195 7.68 130 5.12 155 6.1 168 6.61 10.6 23.36 F11
DMH12-185W 12 45 200 197 7.76 165 6.5 170 6.69 170 6.69 15 33.1 F11
DMH12-250W 12 55 250 229 9.02 138 5.43 208 8.19 402 8.35 18.2 40.11 F11
DMH12-300W 12 74.5 300 260 10.2 169 6.65 208 8.19 402 8.35 24.1 53.12 F40
DMH12-350W 12 90 350 306 12.1 169 6.65 208 8.19 402 8.35 28.5 62.81 F40
DMH12-380W 12 100 380 328 12.9 171 6.74 404 8.43 408 8.59 31 68.32 F11
DMH12-420W 12 112 420 328 12.9 171 6.74 404 8.43 408 8.59 31.6 69.65 F11
DMH12-440W 12 123 440 331 13 176 6.93 404 8.43 408 8.59 34 74.9 F12
DMH12-520W 12 138 520 342 13.5 172 6.77 283 10.8 288 10.9 44 97 F11
